Project Description

(Last Updated On: March 26, 2019)

led emergency batten |tri proof fixture , waterproof IP65 and IK10, high lumen, the customized function is available, dimmable, microwave/daylight sensor, emergency.

FUNCTIONS PARAMETERS
Model No.: Brav60-40W, Brav120-80W, Brav150-100W
Power: 40W/80W/100W
Lumen: 4000lm/8000lm/10000lm
Size: L600*W130*H53mm/L1200*W130*H53mm/L1500*W130*H53mm
Input Voltage: AC100V-240V
Power Factor: >0.95
CCT: 3000K, 4000K, 5000K, 6000K
CRI: Ra>80 and R9>10
Light efficacy: >100LM/W
Beam Angle: 120°
IP grade: IP65 & IK10
Lifespan: 40,000H at 40℃ ambient temperature
Work Temperature: -20 – 40℃
Installing way: Surface mounted, Suspended
Material: PC cover + Aluminum base
Accessory: Manual and 1 set of installation screws
Description: led emergency tri-proof light|led tri-proof light 50w, waterproof IP65 and IK10, high lumen >100lm/w, DALI/Silicon/0-10V/Switch DIMMABLE, Remote/Wireless control, Microwave/Radar/PIR/Daylight Sensor, Emergency available, For Parking lot/Apartment/Supermarket Projects.
FEATURES
Power Factor 95%
Efficiency 85%
IP grade IP 65
IK grade IK 10
  • IP65 and IK10
  • Epistar 2835SMD
  • Meanwell led driver
  • >100lm/w
  • 5 years warranty
